Mobile Drum Ore Stone Gravel Sand Washing Equipment Plant

Brand Name : ZR

Model Number : XS

Place of Origin : Shanghai, China

MOQ : 1 Piece

Price : Price Negotiable

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 1000PCS/Year

Delivery Time : 20-30 days

Packaging Details : Nude Cargo/Pallet/Wooden Case/Customize

Type : Wheel Sand Washer

Cleaning Quantity : 180-250T/H

Speed of Screw : 21rpm

Motor Type : AC Motor

Motor Power : 11kw

Wheel Diameter : 4500mm

Max Enter Particle : 10mm

HS Code : 8474100000

Contact Now

Large Capacity XS4520 Mining Sand Washing Machine

Technical Parameters

Model: XS4520

Wheel Diameter: 4500mm

Max Enter Particle Size: 10mm

Cleaning Capacity: 180-250t/h

Motor Power: 11kw

Model technical parameters

Model	Wheel diameter (mm)	Particle size (mm)	Cleaning quantity (T/H)	Power (KW)	Dimension (mm)
XS2510	2500	≤10	60-100	4	322021252670
XS3010	3000	≤10	60-100	4	3670×1970×3140
XS3015	3000	≤10	100-150	5	3670×2670×3140
XS3020	3000	≤10	150-250	7.5-11	3670×3300×3200
XS4520	4500	≤10	180-250	11	5170×3300×4700
XS6020	6000	≤10	220-300	18.5	6700×3700×6400

Feature
1.This machine's structure is simple. The impeller drive device is separated with water and the watered materiel
avoiding that the bearing is damaged by Deeping in water, sand, or contamination.
2. This machine has obvious advantages compared with screw sand washer. The details are as follows:
a. The medium and fine sand are washed away less. The washed construction sand's gradation and modulus of
fineness can get the standard which is regulated in national ' construction sand' and ' construction scree and gravel'.
b. There are almost no wearing parts except screen mesh.

Application Scope

1.Aggregate Washing: Pebble, Basalt, Limestone, Granite, Andsite, Etc.
2.River Sand Washing: Naturel River Sand.
3.Solid Waste Washing: Construction Waste.
4.Sea Sand Washing: Sea Sand, Beach Sand, Etc.
